API-DIO(WDM) for USB_img1API-DIO(WDM) for USB_img1

API-DIO(WDM) for USB

  • A maximum of 16 boards are controllable. In addition, the driver enables to control up to 256 boards.
  • Digital I/O can be performed from the specified ports.
  • Digital I/O can be performed from the specified bits.
  • Hardware chattering can be prevented by setting the digital filter.
  • The information of boards can be acquired.
  • The callback procedure to accept Interrupt / Trigger notice is provided for applications without window, such as DLL or Resident Program.
Request Quote


    Email Verification Code (required)



    SKU: API-DIO(WDM) for USB Category: Tag: Brand:
    Description
    Specifications
    Ordering Informations
    Overview / Features

    API-DIO(WDM) is the Windows version driver library software that provides products in the form of Win32 API functions (DLL). Various sample programs such as Visual Basic and Visual C++, etc is provided.

    • A maximum of 16 boards are controllable. In addition, the driver enables to control up to 256 boards.
    • Digital I/O can be performed from the specified ports.
    • Digital I/O can be performed from the specified bits.
    • Hardware chattering can be prevented by setting the digital filter.
    • The information of boards can be acquired.
    • The callback procedure to accept Interrupt / Trigger notice is provided for applications without window, such as DLL or Resident Program.

    Specifications

    Specifications
    Software Development Kit
    Type Win64 API (WDM); Win32 API (WDM)
    Supported Development Environment
    Supported Development Environment Visual C#; Visual C++; Visual Basic
    Supported OS
    Supported OS Windows 10 (64-bit); Windows 10 (32-bit); Windows 8 / 8.1 (64-bit); Windows 8 / 8.1 (32-bit); Windows 7 (64-bit); Windows 7 (32-bit); Windows XP (32-bit)
    Supported Series
    Supported Series PC-HELPER
    Supported Devices（Digital I/O）
    Model
    USB Module di-16ty-usb_rgb_96dpi_500x500DI-16TY-USB DI-32(USB) dio-0808ly-usb_high_rgb_96dpi_500x500DIO-0808LY-USB
    DIO-0808RN-USB dio-0808ty-usb_rgb_96dpi_500x500DIO-0808TY-USB DIO-128SLX-USB
    DIO-1616BX-USB DIO-1616HN-USB DIO-1616LN-USB
    DIO-1616RYX-USB DIO-16/16(USB) dio-24dy-usb_high_rgb_96dpi_500x500DIO-24DY-USB
    DIO-48DX-USB dio-6464lx-usb_-usb_rgb_96dpi_500x500DIO-6464LX-USB do-16ty-usb_rgb_96dpi_500x500DO-16TY-USB
    DO-32(USB) rry-16cx-usb-usb_rgb_96dpi_500x500RRY-16CX-USB dio-1616lx-usb_rgb_96dpi_500x500DIO-1616LX-USB
    DIO-3232LX-USB – –

    Ordering Informations

    Ordering Information
    Model Description Certification
    API-DIO(WDM) for USB Digital I/O Driver API-DIO(WDM) for USB

      –

      Options
