| HIGH-SPEED FRAME RATE | High-frame rate up to 1000 Hz (slower speeds are possible using longer integration times) |
|---|---|
| USB COMMUNICATION | Communication interface: USB 2.0, high-speed (480 Mbps) with industrial connector M12 |
| USB POWERED | Power: 5 VDC through USB connection |
| SHUTTER INCORPORATED | Shutter incorporated for 1-pt offset correction |
| LENS INCLUDED |
Lens: f=24 mm, F#1.2, FoV 10.25ºx10.25º (IP-67) Additional lens option: f=48 mm, F#1.6, FoV 5.1ºx5.1º (IP-67) |
| DLL FOR CUSTOM SOFTWARE DEVELOPMENT | SDK library for C: available |
| DETECTION PERFORMANCE | Minimum temperature of detection: 100 ºC |
| Miniaturized uncooled infrared MWIR camera for industrial applications | Communication interface: USB 2.0, high-speed (up to 480 Mbps) |
|---|---|
| Band of detection: MWIR (1 – 5 microns) | Data transmission: raw data, 10 bits |
| Peak wavelength of detection: 3.7 microns | Lens: (1) f=24 mm, F#1.2, FoV 10.2ºx10.2º (IP67-rated) – (2) f=48 mm, F#1.6, FoV 5.1ºx5.1º (IP67-rated) |
| FPA resolution: 32×32 (1024 pixels) | Integrated temperature sensor |
| Shutter incorporated for 1-pt offset correction | Dimensions (in mm): 98.0 (L) x 49.5 (W) x 61.0 (H) (connector in the back) |
| Integration time: adjustment via software (100 – 500 us) | Weight: 250 grams |
| Maximum frame rate: 1000 Hz (slower rates are possible using longer integration times) | Minimum temperature of detection: 100 ºC |
| Snapshot image acquisition | IP67-rated metal housing with CS-mount optics interface |
| Electrical interface: USB powered, industrial M12 mini-USB connector in the back (optional: connector in the bottom part) | Water-block and DLC coating for harsh environment |
| Software included: NIT SOFTWARE SUITE (Acquisition and visualization SW) | DLL for custom software development available |
