The SRV-2UA100D is intended for 5G-based, low latency edge computing solutions that require a compact design—such as industrial sites and retail locations where data is created and analyzed. Its tool-less removal of all storage means simplicity plus the extra security you need. With state-of-the-art technology in a short-depth enclosure, the SRV-2UA100D delivers robust and flexible edge computing to compact deployments. The adaptive nature of its bandwidth and low response time makes it optimized for today’s more data-hungry applications like 5G and real-time analysis.
| Type | 2U |
|---|
| Supported OS | Linux Debian; Linux Fedora; Linux Red Hat Enterprise Server; Linux Rocky; Linux Scientific; Linux SUSE Enterprise Server; Linux openSUSE; Linux Ubuntu Server |
|---|---|
| Virtualization software | – |
| CPU Generation (Development code) | 4th Gen.(Genoa) |
|---|---|
| Processor | AMD EPYC 9734x; AMD EPYC 9654; AMD EPYC 9384; AMD EPYC 9124 |
| CPU socket | SP5 |
| RAS | – |
| GPU | NVIDIA RXT 4500 Ada 24GB |
| AI Performance | – |
| Security | TCG TPM 2.0 |
| Type | DDR5-RDIMM 4800MHz |
|---|---|
| Slots | 8 |
| Capacity | Up to 4TB |
| Video | 1x Mini DisplayPort |
|---|---|
| LAN | 1x Gigabit Ethernet RJ45(dedicated to BMC management) |
| Wireless | – |
| Audio | – |
| I/O | 2x USB3.2 Gen1; 2x USB2.0; 1x RS-232C |
| Memory card | – |
| Video | – |
|---|---|
| LAN | – |
| Audio | – |
| I/O | – |
| Power connector | – |
| Expansion bus | 2x M.2 Key M (22110/2280); 2x PCI Express 5.0(x16) double deck (Full Height/Full Length); 1x PCI Express 5.0(x16) (Half Height/Half Length); 2x PCI Express 5.0(x8) (Full Height/Half Length); 1x OCP 3.0 Mezz. PCI Express 5.0(x16) |
|---|---|
| Drive bay | E1.S 8 bay 9.5mm; E3.S 8 bay 7.5mm |
| Input voltage | – |
|---|
| Operating temperature | 0 to 35°C (50 to 95°F) |
|---|---|
| Storage temperature | -10 to 60°C (14 to 140°F） |
| Standards & Certifications | – |
| Model | Description | Certification |
|---|---|---|
| SRV-2UA100D | 2U Edge Server / AMD Gen. EPYC Processors(Genoa) |
– |
This product is ordered by BTO (Build to Order) method. Please inform your sales contact of your BTO menu selections and request a quotation.
| CPU |
|
|---|---|
| Memory |
|
| OS |
|
| Drive Bays |
|
Power Supply |
|
