ATEX:Ex II 2G Ex eb q [ib] IIC T4 GbEx II 2D Ex tb IIIC T120 °C Db
IECEx:Ex eb q [ib] IIC T4 GbEx tb IIIC T120 °C Db
US & Canada:Class I, Division 2, Groups A, B, C, D T4(A)Ex eb q [ib] IIC T4; GbClass II, Division 2, Groups F, G T120°C(A)Ex mb tb IIIC T120 °C; Db
Operation: 0 °C ≤ Ta ≤ +50 °C(32 °F ≤ Ta ≤ +122 °F )Storage: -20 °C ≤ Ta ≤ +60 °C(-4 °F ≤ Ta ≤ +140 °F )extended: -20 °C ≤ Ta ≤ +60 °C(-4 °F ≤ Ta ≤ +140 °F )
| Structure | Front-panel fitting |
|---|---|
| Dimensions | 240 mm x 170 mm x 80 mm |
| Wall cut-out | 226 mm x 153 mm |
| Display | 7″ W TFT colour display 262,144 colours WVGA resolution, 800 x 480 pixels brightness 500 cd/m2 visible surface approx. 152 mm x 91 mm contrast 600:1 |
| Interface | 2 x Ex i USB 2.0 2 x Ex e USB 2.0 1 x Ethernet 100 BaseT |
| Operating system | Windows® 10 IoT or Windows 7® Ultimate or Windows 7® Embedded |
| CPU | CPU Intel® AtomTM (E 3826) Dual Core with 2 x 1.46 GHz RAM: 2 GB (optional: 4 GB) 4 GB internal Flash Drive hard-drive SSD with 128 GB (MLC) |
