8 x Analog in/out Ex e (16 Bit)

MODEX Ethernet Remote I/O Module for zone 1/21

07-7331-2*0A0000

2x Ethernet 100BaseT with integrated switch
- PROFINET
- Modbus TCP
Ex e for measuring circuits and signals with increased safety
LED display
8 x Analog in/out modules for example Transmitter; Power sources; Positioner

Request Quote

Category: Remote I/O

Description

Technical Data

Manuals/Operating Instructions/Guides

Declarations

Data Sheets

Brochures

Documents

Marking

Ex II 2G Ex db eb IIC T4 GbEx I M2 Ex db eb I MbEx db eb IIC T4 GbEx db I Mb

Ambient Temperature

-40 °C to +60 °C at T4

Certification

ATEX: DE EN
IECEX: EN
CSA: EN
INMETRO: PT

Technical Data

Protection class	Module: IP 66 EN/IEC 60529 Terminals: IP 20 EN/IEC 60529 Terminals with cover: IP 30 EN/IEC 60529
Structure	Flameproof, clip-on enclosure for TH 35 rail
Dimensions	see data sheet
Material	High-quality thermoplastic
Storage temperature	-40 °C to +60 °C
Weight	2.1 kg
Display	ON, L/A1, L/A2, BF, SF Input / Outputs: LED per channel
Voltage	Supply voltage (L+, L-): DC 24 V (20 bis 30 V)
Analog in
Resolution	16 Bit
Signal range	4…20 mA
Short/break detection	yes
Internal resistance	15 Ω

Manuals/Operating Instructions/Guides

Operating instruction – MODEX Ethernet Remote I/O – Ex e

EN
DE

FR

Declarations

Declaration of Conformity 01-7331-7C0029

DE
EN
FR

Data Sheets

Data Sheet – MODEX Ethernet Remote I/O – Ex e

EN
DE

Brochures

MODEX Flyer

DE
EN

MODEX system description

EN
DE

Documents

MODEX_07-7331-_170x102x96_mm.stp

.STP
