This product is a BTO industrial computer that support an 13th generation Intel® Core™ processor series or 12th generation Celeron® processor G6900T. The Intel® Q670 chipset with DDR5 memory (128GB) provides advanced computing and graphical performance. This product features a variety of interfaces such as one each port of DVI-I, HDMI, DisplayPort, eight USB 3.2 Gen1 (USB 3.0) ports (front: 2, rear: 6), four USB 2.0 ports (front: 2), one serial port (RS-232C/422A/485×1), two 2.5BASE-T ports, and one 1000BASE-T port, which can be used in a wide range of embedded applications such as general-purpose PC OS-based controllers and information terminals. Expansion slots : PCI-Express 3.0(x16) slot x1, PCI-Express 3.0(x4) slot x2, PCI slots x1.
| Mounting | Desktop; Wall Mount |
|---|
| Supported OS | Windows 11 IoT Enterprise LTSC 2024; Windows 10 IoT Enterprise 2021 LTSC 64-bit |
|---|
| CPU Generation (Development code) | 13th Gen. (Raptor Lake); 12th Gen. (Alder Lake-S) |
|---|---|
| Processor | Core i7-13700TE; Core i5-13500TE; Core i3-13100TE; Celeron G6900TE |
| CPU socket | – |
| Memory | up to 128GB |
| RAS | Hardware monitor (Fan speed / Temperature / Voltage); Remote power-on; Remote reset; Watchdog timer |
| GPU | – |
| AI Performance | – |
| Security | TCG TPM 2.0 |
| Video | 1x DisplayPort; 1x HDMI; 1x DVI-I |
|---|---|
| LAN | 2x 2500BASE-T/1000BASE-T/100BASE-TX/10BASE-T; 1x 1000BASE-T/100BASE-TX/10BASE-T |
| Wireless | – |
| Audio | 1x Line out; 1x Line in; 1x Mic-in |
| I/O | 6x USB3.2 Gen2 (USB3.1); 2x USB3.2 Gen1; 1x RS-232C/422A/485 |
| Memory card | – |
| Expansion bus | 1x PCI Express 4.0(x16); 2x PCI Express(x4); 1x PCI |
|---|---|
| Drive bay | 2x 3.5-inch bay (SATA) |
| Input voltage | 100 to 240VAC |
|---|
| Operating temperature | 5 to 40°C (41 to 104°F) |
|---|---|
| Storage temperature | -20 to 60°C (-4 to 140°F) |
| Standards & Certifications | CE; FCC Class A; UKCA; VCCI Class A |
| Model | Description | Certification |
|---|---|---|
| LPC-1800-G | BTO model |
|
This product is ordered by BTO (Build to Order) method. Please inform the dealer about the BTO menu and request a quotation.
