| SENSOR RESOLUTION | 320 (h) x 240 (v) |
|---|---|
| PIXEL PITCH | 12 µm |
| SPECTRAL RESPONSE | 7,8 – 14 µm |
| FRAME RATE | 27 Hz |
| SENSOR SENSITIVITY (NETD) | 65 mK (typ), < 100 mK @ 25 ℃ |
| MICROBOLOMETER | VOx |
| OBJECT TEMPERATURE RANGE | -40 ºC to 330 ºC |
| POWER | 200 mW |
| FOCAL LENGTH | 4 mm | 9.1 mm |
|---|---|---|
| FOV | 56° x 42° | 24° x 18° |
| MINIMUM FOCUS DISTANCE | 0.25 m | 0.90 m |
| DETECTION RANGE | 333 m | 758 m |
| RECOGNITION RANGE | 83 m | 190 m |
| IDENTIFICATION RANGE | 48 m | 108 m |
| F-NUMBER (FOCAL LENGTH/APERTURE) | F#1.00 | |
| FOCUS | Fixed |
|---|---|
| CONNECTOR | Rugged USB industrial connector |
| POWER | 200 mW |
| DIMENSIONS | 28.5 x 28.5 x 55.5 mm |
| WEIGHT | 70 g |
| TRIPOD MOUNT | 1/4-20 UNC |
| FIXING HOLES | Mechanical M2 and M3 fixing holes |
| TEMPERATURE ACCURACY | ±2 °C or ±2 %, whichever is greater |
|---|---|
| EMISSIVITY CORRECTION | Yes |
| OPERATING TEMPERATURE RANGE | 10 ºC to 60 ºC |
|---|---|
| STORAGE TEMPERATURE RANGE | -40 ºC to 80 ºC |
| HUMIDITY | 10% ~ 95% RH, non-condensing |
| PROTECTION | IP67 |
| REGULATORY | ROHS, WEEE, REACH, CE |
