JLT 1214 Rugged Vehicle Mounted Computer

The JLT1214P and JLT1214N computers are the latest generation logistics computers from JLT. With proven reliability and the latest processor technology, they deliver the lowest total cost for a wide variety of logistics applications. They have an integrated 9-36 VDC power supply, but are also available with an isolated 18-60 VDC for electrical truck and forklift installations.

Data Sheet

Request Quote


    Email Verification Code (required)



    Description
    Outstanding value in the warehouse and other logistics applications

    If you’re looking for a reliable workhorse that has been proven in thousands of customer applications around the world, take a look at the JLT1214 family of vehicle-mount logistics computers. They deliver proven reliability and value for a wide range of logistics vehicle types.

    The JLT1214 models incorporate the latest processor technology and the features required for a fast, trouble-free and cost-effective installation. Both can be supplied with an integrated, isolated 18-60 VDC power supply for electrical forklift installations or a non-isolated 9-36 VDC power supply for combustion-powered vehicles.

    The JLT1214P features our PowerTouch™ display technology. It’s virtually unbreakable and provides a user-friendly experience even with a gloved hand. The PowerTouch display overcomes the most common failure point for rugged computers.

    For extreme freezer storage and other sub-zero degree applications, the JLT1214N with heater gives you a heated display to prevent frost formation at low temperatures. The heating element activates automatically when the surrounding temperature approaches 0°C, enabling trouble-free operation in fluctuating temperatures, for example when going in and out of a blast freezer.

    KEY FEATURES

    • Windows operating system
    • 12” XGA LED display with the smallest footprint in its class
    • Intel® Celeron E3845 quad core processor
    • IP65 waterproof and dustproof
    • Virtually unbreakable JLT PowerTouch™ display on JLT1214P
    • Dual-diversity PIFA WLAN antennas
    • Optional heated display for extreme temperatures on JLT1214N
    • Integrated DC/DC with UPS battery solution

    PHYSICAL

    SIZE

    305mm (w) x 240mm (h) x 59mm (d)
    12 inch (w) x 9.4 inch (h) x 2.3 inch (d)

    WEIGHT

    3.5 kg / 7.7 LB

    SYSTEM ARCHITECTURE

    PROCESSOR

    Intel® E38454GB DDR3

    RAM

    4GB DDR3

    BOOT MEDIA

    CFast 16GB, 32GB, 64GB, 128GB

    DISPLAY

    12.1” XGA LED 500 NIT

    1214P – Capacitive touch screen with JLT PowerTouch™ technology and hardened glass
    1214N/1214N Heater – Resistive 4-wire touch screen

    OPERATING SYSTEM

    Windows 10 IoT
    Windows Embedded Standard 7
    Windows 7

    RF OPTIONS

    BLUETOOTH

    v4.2

    GNSS

    A-GPS/GLONASS/BEIDOU (optional)

    WLAN

    Dualband WLAN 802.11 ac, MU-MIMO supported

    WWAN NORTH AMERICA

    4G (LTE) up to 100 Mbps download speed (optional)

    ANTENNAS

    User configurable external or internal WLAN and Bluetooth antennas
    WLAN dual diversity antennas (PIFA)

    ENVIRONMENT

    OPERATING TEMPERATURE

    -30°C to 55°C / -22°F to 131°F

    STORAGE TEMPERATURE

    -35°C to 75°C / -31°F to 167°F

    CONNECTOR SEALING

    Roxtec sealing cable protection (optional)

    HUMIDITY

    10–95% RH

    DUST AND WATER

    IP65 – IEC 60529:2001

    VIBRATION

    5–500 Hz/0,04 m/s2 XYZ – IEC 60068-2-64 Fh

    SHOCK

    30g for 11ms XYZ – IEC 60068-2-27

    MIL-SPEC

    810G in applicable areas

    INTERFACES

    AUDIO

    HD audio
    Waterproof stereo speakers

    BUTTONS

    LED dimming +/-
    Power

    PORTS

    1x Ethernet 10/100/1000
    1x RS232 with 5V
    4x USB 2.0

    BATTERY

    Internal battery for graceful shut down at unexpected power outages

    INPUT

    1214P/1214N – 9-36 VDC unisolated
    1214P/1214N/1214N Heater – 18-60 VDC isolated
