The CONPROSYS Robust I/O series is a standalone remote I/O module that supports the Modbus communication protocol. It is designed to be environmentally resistant, with excellent noise resistance and overvoltage and overcurrent protection circuits, and can be used in industrial applications such as monitoring factory equipment and production lines and process control.
| Series | CONPROSYS Robust I/O |
|---|---|
| Bus Specification | RS-485 (Modbus-RTU) |
| Size | – |
| Used Connector | – |
| Type | Thermocouple |
|---|---|
| Input Channels | Differential 10-ch |
| Compatible Sensor | Type B; Type C; Type E; Type J; Type K; Type L; Type M; Type N; Type R; Type S; Type T; Type LDIN43710 |
| ADC Resolution | 16-bit |
| Sampling Rate | 100msec (10Hz) |
| Input Channels | – |
|---|---|
| Output Channels | – |
| Bi-directional I/O Channels | – |
| Response Time (Input) | – |
| Response Time (Output) | – |
| Operating Voltage (Input) | – |
| Operating Voltage (Output) | – |
| Input Circuit | – |
| Output Circuit | – |
| Built-in Power Supply | – |
| Number of Channels | – |
|---|---|
| Counting System | – |
| Response speed | – |
| Supported OS | – |
|---|
| Model | Description | Certification |
|---|---|---|
| CPSR-M7018ZGS | 10ch 16bit Thermocouple Input |
|
