The new product is a small embedded PLC (Programmable Controller) that implements the world-widely used software PLC “CODESYS” on our original board computer based on the embedded module Compute Module 4 (CM4) of Raspberry Pi. Utilizing our vast assets of peripheral devices for Raspberry Pi, including our “CPI series,” it can be used in the world standard PLC language compliant with IEC 61131-3.
| Series | PC-HELPER CPI |
|---|---|
| Communication Ports | Ethernet (LAN) |
| Programming | CODESYS (IEC61131-3) |
| Stack bus | Raspberry Pi HAT (40pin GPIO) |
| Function | EtherCAT master; EtherNet/IP Adapter; EtherNet/IP Scanner; Modbus-TCP Master; Modbus-TCP Slave; OPC UA server; OPC UA client; Profinet IO Controller; PROFINET IO Device |
| Input Channels | – |
|---|---|
| Output Channels | – |
| Bi-directional I/O Channels | – |
| Response Time (Input) | – |
| Response Time (Output) | – |
| Operating Voltage (Input) | – |
| Operating Voltage (Output) | – |
| Input Circuit | – |
| Output Circuit | – |
| Built-in Power Supply | – |
| Input Channels | – |
|---|---|
| Input Range | – |
| ADC Resolution | – |
| Sampling Rate | – |
| Input Buffer Memory | – |
| Output Channels | – |
| Output Range | – |
| DAC Resolution | – |
| Update rate | – |
| Output Buffer Memory | – |
| Number of Channels | – |
|---|---|
| Counting System | – |
| Response speed | – |
| Number of Channels | – |
|---|---|
| Transmission Speed | – |
| Isolation Property | – |
| Transmission Method | – |
| Model | Description | Certification |
|---|---|---|
| CPI-PS10CM4-2E021 | Small Embedded All-in-One PLC |
|
| Items | Item Name |
|---|---|
| CPI-AI-1208LI | Analog input Raspberry Pi card 12-bit 8ch (differential 4ch) voltage input/current input |
| CPI-AO-1602LC | Analog Output Raspberry Pi card 16bit 2ch voltage/current output |
| Items | Item Name |
|---|---|
| CPI-DI-16L | Digital input Raspberry Pi card 16ch (isolated 12 – 24VDC) |
| CPI-DIO-0808L | Digital I/O Raspberry Pi card 8ch/8ch (isolated 12 – 24VDC) |
| CPI-DIO-0808RL | Digital I/O Raspberry Pi card 8ch/8ch (negative-common isolated 12 – 24VDC) |
| CPI-DO-16L | Digital output Raspberry Pi card 16ch (isolated 12 – 24VDC) |
| CPI-DO-16RL | Digital output Raspberry Pi card 16ch (negative-common isolated 12 – 24VDC) |
| CPI-RRY-16 | Solid-state relay Raspberry Pi card 16ch (Contacts A isolated – 30VDC) |
| Items | Item Name |
|---|---|
| CPI-CNT-3201I | Counter Input Raspberry Pi card 32bit Up-Down Counter 1ch Single-Phase/2-Phase (A/B/Z) |
| Items | Item Name |
|---|---|
| CPS-PWD-30AW24-01 | CONPROSYS 24VDC 1.3A(Max.) Power Supply Unit |
| CPS-PWD-90AW24-01 | CONPROSYS 24VDC 3.8A(Max.) Power Supply Unit |
| PWA-65AWD9 | AC Adapter(19VDC 3.42A) |
| Items | Item Name |
|---|---|
| CPI-DIN01 | DIN Rail Mount Kit for Raspberry Pi card |
