| Mounting | VESA Arm; Desktop |
|---|
| LCD size | 18.5-inch |
|---|---|
| LCD resolution | 1366 x 768 (FWXGA) |
| Touch panel resolution | – |
| Detection method | Projected capacitive touch (PCAP) |
| Video input | DisplayPort; DVI; Analog RGB |
|---|---|
| Touch panel input | USB; RS-232C |
| Input voltage | 12VDC; 100 to 240VAC |
|---|
| Operating temperature | 10 to 40°C (50 to 104°F) |
|---|---|
| Storage temperature | -20 to 60°C (-4 to 140°F) |
| Standards & Certifications | CB; CE; FCC Class B; UL |
| Model | Description | Certification |
|---|---|---|
| CM-ME185P45HD (Ordering PN: 22125) |
18.5″ 1366 x 768, 450 nits PCAP Touch Medical Monitor, 10 to 40 C |
|
