The CA-ME215PE4 is a 21.5” elegant fanless design AIO perfect for life sciences, medical carts, and medical applications. This AIO features Intel Tigerlake 11th Gen UP3 Core-i Processor and offers up to 64 GB RAM and 128 GB storage. This product also features required certifications and protections to work smoothly in these applications: front IP65 agaisnt dust and water ingression and IEC 60601. The CA-ME215PE4 offers performance and durability for optimal productivity in medical applications.
| Mounting | VESA 100 x 100; VESA 75 x 75; Desktop; Wall Mount |
|---|
| Supported OS | Windows 10 IoT Enterprise 2019 LTSC 64-bit |
|---|
| CPU Generation (Development code) | 11th Gen. (Tiger Lake UP3) |
|---|---|
| Processor | Core i5-1145G7E |
| CPU socket | – |
| Memory | up to 64GB |
| RAS | – |
| GPU | – |
| AI Performance | – |
| Security | TCG TPM 2.0 |
| LCD size | 21.5-inch |
|---|---|
| LCD resolution | 1920 x 1080 (Full HD) |
| Touch panel resolution | 1920 x 1080 |
| Detection method | Projected capacitive touch (PCAP) |
| Video | 1x HDMI |
|---|---|
| LAN | 2x 1GbE |
| Wireless | Wireless LAN IEEE802.11ax/ac/a/b/g/n |
| Audio | 1x Audio combo connector (Mic in or Line Out); 2x 3W Stereo Speaker |
| I/O | 4x USB3.2 Gen1 (USB3.0); 2x USB2.0; 2x RS-232C; 1x RS-232C/422A/485; 1x RS-232C/485 |
| Memory card | – |
| Expansion bus | M.2 socket |
|---|---|
| Drive bay | – |
| Input voltage | 19VDC |
|---|
| Operating temperature | 0 to 40°C (32 to 104°F) |
|---|---|
| Storage temperature | -20 to 60°C (-4 to 140°F) |
| Standards & Certifications | IEC 60601 |
| Model | Description | Certification |
|---|---|---|
| CA-ME215PE4-W81WD | 21.5” Medical Grade AIO, Intel Tiger Lake UP3 Core-i5 Processor, Windows® 10 IoT Enterprise Entry (64bit, Multi-Language), 8G RAM, 128G SSD, WiFi, DC |
– |
