ATEX:Ex II 2(1)GEx eb mb ib [ib pyb] [ia Ga] IIC T4 GbEx eb mb ib [ib pyb] [ia Ga] IIC T5 GbEx III 2(1)DEx tb [ib pyb] [ia Da] IIIC T130 °C DbEx tb [ib pyb] [ia Da] IIIC T95 °C Db
IECEx:Ex eb mb ib [ib pyb] [ia Ga] IIC T4 GbEx eb mb ib [ib pyb] [ia Ga] IIC T5 GbEx tb [ib pyb] [ia Da] IIIC T130 °C DbEx tb [ib pyb] [ia Da] IIIC T95 °C Db
Operating temperature-25 °C to +60 °C @ T4(-13 °F to 140 °F @ T4)-25 °C to +50 °C @ T5(-13 °F to 122 °F @ T5)Storage temperature-20 °C to +60 °C(-4 °F to 140 °F)
| Protection class | IP 66 according to EN/IEC 60529 IP 64 according to EN/IEC 60079-0 |
|---|---|
| Pressure range | 0 to 25 mbar for all pressure switching levels |
| Purge time | 0 to 120 minutes (adjustable) |
| Temperatures | Operating temperature -25 °C to +60 °C @ T4 (-13 °F to 140 °F @ T4) -25 °C to +50 °C @ T5 (-13 °F to 104 °F @ T5) Storage temperature -20 °C to +60 °C (-4 °F to 140 °F) |
| Voltage | AC Variant: AC 100 V up to 230 V DC Variant: DC 24 V up to 44 V |
| Material | V4A stainless steel |
| Display | 6 LEDs for status display |
| Relay | Enable contact, switched input voltage max. load 5A Enable relay, potentiel free, 4 NO 2x Signal relay for status transmission (potentail free), CO |
| Weight | 6.8 kg |
