PT-M15SB-4600-G_img1PT-M15SB-4600-G_img1

PT-M15SB-4600-G

  • High Performance Processing
  • Multi-Display Support
  • Advanced Expansion & Storage
  • Rich Connectivity Options
  • Enhanced Reliability & Security
  • IP65 Front Bezel

Data Sheet PDF

Request Quote


    Email Verification Code (required)



    SKU: PT-M15SB-4600-G Category: Tag: Brand:
    Description
    Specifications
    Ordering Informations
    Overview / Features

    • High Performance Processing
      • Supports Intel® 13th Gen LGA-1700 CPU with Intel® R680E chipset and DDR5-4800 memory (up to 16GB).Powerful computing core to handle smart factory and automation tasks with ease.
    • Multi-Display Support
      • Flexible display output to support monitoring and HMI multitasking. Dual display support: DisplayPort (up to 4096×2304) and DVI-D/VGA (up to 1920×1200)
    • Advanced Expansion & Storage
      • Triple M.2 slots: Key E (Wi-Fi), Key B (4G/5G with SIM), Key M (NVMe SSD with Intel RST) Seamless wireless connectivity and high-speed storage for edge computing demands.
    • Rich Connectivity Options
      • Dual 2.5GbE LAN (Intel® i226IT), 4x USB 3.2 Gen2, 2x USB 2.0, multiple serial ports, GPIO Comprehensive I/O to easily integrate with a wide range of industrial devices and sensors.
    • Enhanced Reliability & Security
      • TPM 2.0, hardware monitoring, watchdog timer, wide voltage input (12–24V DC ±10%) Built-in protection and stability for nonstop performance in mission-critical operations.
    • IP65 Front Bezel
      • The aluminum front bezel is waterproof and dust-proof, making it suitable for harsh industrial conditions. Rugged design that stands up to the toughest factory environments.

    Specifications

    Specifications
    Mechanical Design
    Mounting Panel Mount
    Software Support
    Supported OS Windows 11 24H2 LTSC 2024 64-bit
    Core System
    CPU Generation (Development code) 13th Gen. (Raptor Lake-S)
    Processor Core i7-13700TE; Core i5-13500TE
    CPU socket LGA1700
    Memory up to 64GB
    RAS Hardware monitor (Fan speed / Temperature / Voltage); Watchdog timer
    GPU –
    AI Performance –
    Security TCG TPM 2.0; NIST SP800-147 (BIOS Write Protect); Secure Boot USB Key
    Touch Screen
    LCD size 15-inch
    LCD resolution 1024 x 768 (XGA)
    Touch panel resolution 1024 x 768
    Detection method Projected capacitive touch (PCAP)
    Interface
    Video 1x DisplayPort; 1x Analog RGB
    LAN 2x 2500BASE-T/1000BASE-T/100BASE-TX/10BASE-T
    Wireless –
    Audio 1x Line out; 1x Mic-in
    I/O 4x USB3.2 Gen2; 2x USB2.0; 2x RS-232C; 1x RS-232C/422A/485
    Memory card 1x CFast slot
    Expansion Slot
    Expansion bus –
    Drive bay 2x 2.5-inch bay (SATA)
    Power
    Input voltage 12 to 24VDC
    Environment
    Operating temperature 0 to 50°C (32 to 122°F) (with no airflow)
    Storage temperature -10 to 60°C (14 to 140°F)
    Standards & Certifications CE; FCC Class A; UKCA; VCCI Class A

    Ordering Informations

    Ordering Information
    Model Description Certification
    PT-M15SB-4620-G3000 13th Gen (Raptor Lake-S) Core i5-13500TE / DC Power Supply
    • CE marking
    • FCC compliant
    • VCCI
    PT-M15SB-4630-G3000 13th Gen (Raptor Lake-S) Core i7-13700TE / DC Power Supply
    • CE marking
    • FCC compliant
    • VCCI
